| model | SMT-BP-10-300 | SMT-BP-30-300 | SMT-BP-60-300 | SMT-BP-100-300 | SMT-BP-150-300 | SMT-BP-200-300 |
| Max Force (KN) | 10 | 30 | 60 | 100 | 150 | 200 |
| Max Stroke (mm) | 300 | 300 | 300 | 300 | 300 | 300 |
| Max Speed (mm/s) | 300 | 200 | 200 | 160 | 110 | 140 |
| Repeat Position Accuracy (mm) | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 |
| Force Measurement Accuracy (%) | 1 | 1 | 1 | 1 | 1 | 1 |
| Rated Voltage (V) | 380 | 380 | 380 | 380 | 380 | 380 |
| Service Life | >5 million | >5 million | >5 million | >5 million | >5 million | >5 million |
| Ambient Temperature | 0-40°C | 0-40°C | 0-40°C | 0-40°C | 0-40°C | 0-40°C |
| Noise (db) | <75 | <75 | <75 | <75 | <75 | <75 |
| Rated Power (KW) | 1.5 | 1.5 | 3 | 4.4 | 4.4 | 7.5 |
Realize the beauty of intelligent connection of sheet metal parts
